emUSB-Host
The emUSB-Host software complies with the USB standard specifications as set by the USB Implementors Forum. It supports all transfer modes (control, bulk, interrupt, isochronous) at all speeds. USB pipe management and extended error recovery mechanisms required for reliable operation are implemented internally. Sophisticated test procedures ensure the reliability and quality of the USB host software.
emUSB-Host’s modular design enables applications to either access the USB host programming interface directly or to use APIs made available via by class drivers.
emUSB-Host can handle multiple devices as well as hubs simultaneously and fully supports hot plugging of devices and hubs. The programming interface supports dynamic device enumeration and identification.
emPower-USB-Host
Key features
- Professional USB-Host software for embedded systems
- Direct support from the product developers
- Highly portable and uniform API for all supported controllers
- High performance, small memory footprint in RAM and ROM
- Simple to integrate into your embedded environment
- emPower-USB-Host Dual USB platform available
emUSB-Host components
SEGGER’s USB host stack designed to work on any embedded system with a USB host controller. Bulk communication along with all other transfer modes is supported. All commonly used standard device classes are supported. USB trees with multiple hubs are supported as well.
emUSB-Host consists of three layers. These layers are a driver for hardware access, the emUSB-Host core, and at least one USB protocol layer.
SEGGER recommends to purchase emUSB-Host as a complete package by selecting the emUSB-Host PRO package. It includes support for the most common use cases, such as handling human interface devices for user interaction, handling USB sticks to export and import data, printer support and serial communication support. The following table shows, which modules are part of the PRO package and which are optionally available.
| Component | Description | emUSB-Host BASE | emUSB-Host PRO |
| USB protocol layer | |||
| Audio | emUSB-Host Audio component | Optional | Included |
| CCID | emUSB-Host CCID class component. | Optional | Included |
| CDC | emUSB-Host Communication Device Class component. | Optional | Included |
| CP210x | emUSB-Host CP210x UART support. | Optional | Included |
| FT232 | emUSB-Host FTDI UART component. | Optional | Included |
| HID | emUSB-Host Human Interface Device Class component. | Included | Included |
| LAN | emUSB-Host LAN component. | Optional | Included |
| MIDI | emUSB-Host MIDI class component. | Optional | Included |
| MSD | emUSB-Host Mass Storage Device Class component. | Included | Included |
| MTP | emUSB-Host Media Transfer Protocol component. | Optional | Included |
| Printer | emUSB-Host Printer component. | Optional | Included |
| Vendor | emUSB-Host Vendor class component. | Optional | Included |
| Video | emUSB-Host Video component | Optional | Optional |
| Core layer | |||
| emUSB Core | The emUSB-Host core is the intrinsic USB stack | Included | Included |
| Hardware layer | |||
| Driver | USB controller driver | Optional | One item included |
Audio
USB Audio Host class
The emUSB-Host-Audio class allows audio devices, such as microphones, speakers or musical players to communicate with a USB host target. The class allows to record or play audio through the host.
Application samples for emUSB-Device Audio
Microphone
Speakers
Sound Bar
Headset
USB sound card
CCID
CCID Class
SEGGER’s emUSB-Host CCID Class provides an easy-to-use interface to handle smart card readers and communicate with smart cards.
Peripherals compatible with emUSB-Host CCID Class
Card reader
NFC card reader
RFID card reader
CDC
Communication Device Class
The USB Communication Device Class (CDC) provides access to COM port devices via USB. This enables communication via modems for mobile networks such as GSM/3G/LTE or cable based network modems. Any device which uses CDC for configuration and data transmission, such as a point-of-sales terminal, can be accessed via the CDC class driver as well.
Peripherals compatible with emUSB-Host CDC
Modem
Fax
POS-Terminal
CP210X
CP210X Device Driver
Many devices formerly connected via UART have been equipped with USB interfaces using serial to UART converters such as the CP210x USB-to-UART Bridges from Silicon Labs. emUSB-Host is capable of easily addressing such devices.
Peripherals compatible with emUSB-Host CP210X
CP2102 USB to UART Bridge
FT232
FTDI FT232 Device Driver
Many devices formerly connected via UART have been equipped with USB interfaces using serial to UART converters such as the FTDI UART and FT-X devices from FTDI. emUSB-Host is capable of easily addressing such devices.
Peripherals compatible with emUSB-Host FTDI UART
USB to RS232 Converter
HID
Human Interface Device class
The Human Interface Device class (HID) supports the handling of devices which are used by humans to control the operation of computer systems. The class enables the use of input devices such as keyboards, mice, trackballs, touch-controllers, barcode scanners, joysticks, game controllers, RFID readers. And even devices which do not require direct human control such as digital thermometers, software protection dongles, uninterruptible power supplies.
Peripherals compatible with emUSB-Host HID
Keyboard & Mouse
Barcode Scanner
Touch Screen
Joystick
Fingerprint Sensor
RFID Reader
3D Mouse
Trackball
Uninterruptible Power Supply
Weighing Scale
LAN
Ethernet-over-USB adapter support
emUSB-Host LAN provides support for a multitude of Ethernet-over-USB adapters which can easily enable network access for any embedded system with USB host.
USB to Ethernet Adapter
Internet Stick
USB Tethering
MIDI
MIDI Class
The USB class protocol for MIDI is used to interact with music devices and Studio equipment, such as MIDI controllers, sequencers, drum machines, samplers, effects, units, synthesizers, instruments, lighting and recording equipment.
MIDI devices and instruments compatible with emUSB-Host MIDI
Synthesizer
Controller
Effects Unit
MSD
Mass Storage Device Class
The Mass Storage Device class (MSD) is used to get access to external storage media such as USB-sticks, external hard disk drives and memory card readers.
Peripherals compatible with emUSB-Host MSD
Memory Stick
USB Hard Disk Drive
Cardreader
MTP
Media Transfer Protocol
The Media Transfer Protocol (MTP) can be used to transfer files to and from storage devices like digital cameras or smartphones.
Peripherals compatible with emUSB-Host MTP
Smartphone
Camera
Printer
Printer Class
The USB class protocol for printers is used for the handling of output devices, like printers and plotters.
Peripherals compatible with emUSB-Host Printer
Printer
Vendor
Vendor Class
SEGGER’s emUSB-Host Vendor Class provides an easy-to-use interface to devices running custom or proprietary protocols.
Peripherals compatible with emUSB-Host Vendor Class
SEGGER Debug Probe J-Link
Temperature Logger
Software Protection Dongle
Gamepad
Video
USB Video Host Class
The emUSB-Host-Video class allows video devices, such as webcams to communicate with a USB host target. The class allows to receive video from input devices.
Peripherals compatible with emUSB-Host Video Class
Webcam
Advantages of adding USB host to your hardware
- Low cost: The USB connector and the corresponding components are normally cheaper than alternative communication interfaces.
- Reliable: The USB protocol contains measures to ensure data integrity. Errors are detected by the sender and data can be retransmitted.
- Versatile: USB host allows to connect with virtually any other technology. Using a USB host port network connectivity can be added by connecting an Ethernet-over-USB adapter. User input can be added by connecting an external USB display, USB keyboard and USB mouse. Storage capacity can be extended by connecting an MSD stick or hard drive.
- Fast: Multiple speed modes are provided by the USB protocol to accommodate the application’s needs.
- Expandable: USB hubs can be used to connect multiple devices to a USB host.
- Easy to use: The end user only has to connect a cable, a USB device is enumerated without the need for user configuration.
emUSB-Host drivers
emUSB-Host does not contain any hardware dependencies. These are encapsulated through a hardware abstraction layer, called a driver. In order to manage the number of required drivers, emUSB-Host has a flexible driver concept, that supports almost all host controllers in the market. For a complete list of currently supported controllers, press the button below.
Licensing
emUSB-Host is available under various Embedded Software License models and delivered in source code packages. With a wide range of licensing options, emUSB-Host can fulfill commercial requirements as well as technical requirements. All licenses are one-time payments. emUSB-Host is royalty-free and not subscription-based. This makes the software a part of the equipment expenses, keeping the costs static.
